EasyPact CVS100B, 25kA at 415VAC, 16A, TM-D trip unit, 3P3d(LV510300)
EasyPact CVS100B, 25kA at 415VAC, 16A, TM-D trip unit, 3P3d(LV510300) - Image 2
EasyPact CVS100B, 25kA at 415VAC, 16A, TM-D trip unit, 3P3d(LV510300) - Image 3

EasyPact CVS100B, 25kA at 415VAC, 16A, TM-D trip unit, 3P3d(LV510300)

1,750.52 บาท

รายละเอียดสินค้า
EasyPact CVS100B, 25kA at 415VAC, 16A, TM-D trip unit, 3P3d  (LV510300)

asyPact CVS100B is a 3 poles 3d fixed circuit breaker with a high level of performance and cost-saving functionality. It is an optimal choice for small and medium-sized buildings protection applications. The breaking capacity (Icu) is 25kA rms at 415VAC 50/60Hz. The operational voltage is 440VAC 50/60Hz. This product embeds a 16A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an adjustable thermal overload protection and a fixed magnetic protection. This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. EasyPact CVS100B is compliant with international standards (IEC 60947, CCC, EAC). It can be installed in class II insulation switchboards as it is a class II front face device (IEC 60664-1).
